A.025T/PZPPA/TNL/TF/PTV/0150

Model:

A.025T/PZPPA/TNL/TF/PTV/0150

(01-02-000360-00)

Description:

6 mm (1/4″) Accu-Flo™ Clamped Plastic Pump

Accu-Flo™ Series Air-Operated Double-Diaphragm (AODD) Pumps give you the critical external pump control necessary for exacting applications such as batching. Featuring a direct electrical interface that utilizes electrical impulses to stroke the pump instead of differential pressure, the Accu-Flo Series provides a variable stroke rate that you can easily control as needed. To meet your applications, Accu-Flo Series pumps are available as NEMA 5-compliant and come in a variety of voltage options.

Features:

AIR INLET

-1/8″ FNPT

LIQUID INLET

-6 mm (1/4″)

LIQUID DISCHARGE

-6 mm (1/4″)

CONNECTION TYPE

-NPT/BSPT (Threaded)

MAX SUCTION LIFT CAPABILITY

-Rubber – 4.14 m (13.6′) Dry, 9.33 m (30.6′) Wet

-PTFE – 3.96 m (13′) Dry, 9.33 m (30.6′) Wet

MAX FLOW RATE

-Rubber – 12.1 lpm (3.2 gpm)

-PTFE – 11.7 lpm (3.1 gpm)

MAX PRESSURE

-8.6 bar (125 psi)

MAX DIAMETER SOLIDS

-0.4 mm (1/64”)

DISPLACEMENT PER STROKE *

-Rubber – 0.02 L (0.005 gal)

-PTFE – 0.02 L (0.005 gal)

* 1 cycle = 2 strokes
