ANSI B73.1 Process Pump
The Griswold ANSI B73.1 Process Pump, available in diverse sizes and materials, handles various process fluids, abrasives, and corrosives. ASME B73.1-compliant, it features robust power frames, adjustable impellers, and wide mechanical seal options. With high flow/head capabilities and interchangeable parts, it’s a versatile solution for industrial applications.
Description
Specification
Downloads
The 811 ANSI Series is available in a wide range of sizes, capacities and materials to fit virtually any process-fluid applications. With more than 30 selections and multiple design options, we’ve got your application covered – for abrasives, corrosive substances and a wide range of capacities.
Applications:
- Oil & Gas
- Chemical
- Petrochemical
- Water Treatment
- Pulp & Paper
- Breweries
- Grain Processing
- Food Processing
- Poultry Processing
- Automotive
- Pharmaceutical
- Steel
- Semiconductor
- Power Generation
- Textile
Features & Benefits:
- ASME (ANSI) B73.1-compliant.
- Magnetic drain plug.
- Extra-large capacity epoxy-coated oil sump.
- Registered alignment between frame and adapter.
- Standard and low-flow models available.
- Heavy-duty power frames.
- Fully open impellers with rear-adjustment capability.
- Wide variety of mechanical seal options.
- Dynamically balanced impellers.
- Factory certified, high quality genuine parts.
- Part-for-part interchangeable with other centrifugal pumps.
Available Materials:
- Ductile Iron
- 316 Stainless Steel
- Alloy 20
- CD4MCu
| Maximum Flow Rate | |
|---|---|
| Max head | |
| MAX TEMPERATURE |
